They are designed to transmit fluids and gasses uniformly under many field conditions.
Triplanar geonet is made of HDPE and anti-ultraviolet additives, which has the anti-aging, corrosion resistance properties.
Specification of Triplanar Geonet
Drainage network core | Unit | Specification | |||
Unit weight | g/m2 | 750 | 1000 | 1300 | 1600 |
Thickness | mm | 5.0 | 6.0 | 7.0 | 7.6 |
Hydraulic Conductivity | m/s | K×10-4 | K×10-4 | K×10-4 | K×10-4 |
Elongation | % | 50 | 50 | 50 | 50 |
Tensile Strength(core network | KN/m | 8 | 10 | 12 | 14 |
Application of Triplanar Geonet
Geonet can be used in the soft soil stabilization, base reinforcement, embankments over soft soils, seacoast slope protection and reservoir bottom reinforcement, etc. It prevents the slope rock fromfalling down, which avoids the hurt to the human beings and the vehicle on the road; It prevents the road dregs packed by geonet from being washed away, avoids the roadbed distortion and improves the stability of the roadbed; laying the geonet reinforces the road surface, avoids development of the reflection crack.
