PET Nonwoven Geotextile
Quantity

PET Nonwoven Geotextile

    Description

    PET Nonwoven geotextile is non-woven needle punched geotextile, It is made of polyester or polypropylene fibers. It is a kind of insdustrial fabric.

    Description of PET Nonwoven Geotextile

    PET Nonwoven Geotextile is made of polyester or polypropylene in random directions and punched together by needles. GSNW Geotextiles has good impermeability and resistance to deformation, which allows geotextiles be widely applied in civil projects for separation, filtration, reinforcement, protection and drainage.

Specification of PET Nonwoven Geotextile

Serial Number specification 200g 500g Remark
1 Mass-area ratio deviation, % -8 -6
2 Thickness,mm 1.7 3.6
3 Amplitude,deviation,% -0.5 -0.5
4 Breaking strength, KN/m ≥ 6.5 16.0 Vertically and horizontally
5 Breaking elongation,% 25-100 25-100
6 CBR bursting strength, KN/m ≥ 0.9 2.7
7 Equifinal aperture, mm 0.07~0.2 0.07~0.2
8 Vertical permeability coefficient, cm/s Kx(10-1~10-3) K=1.0~9.9
9 Ripping strength, KN/m ≥ 0.16 0.42 Vertically and horizontally

Application of PET Nonwoven Geotextile

Geotextiles are permeable nonwoven fabrics used to separate, filter, reinforce, protect or drain. Geotextiles allow filtration or separation of granular layers in roads and rail applications, used to protect membranes in landfill applications, used in coastal defence applications and used in landscaping to protect surfaces and structures from weeds and root growth.

Geotextiles are availabel as woven and non-woven. As liner protection, against physical damage, the non wovens are normally the answer. They are made up of fibers of polyester or polypropylene in random directions and punched together by needles during the manufacturing process. Geotextiles are commenly used to separate layers like clay and drainage and to protect liner from damage.
