PP Needle Punched Nonwoven Geotextile
Quantity
Inquiry

PP Needle Punched Nonwoven Geotextile

    Description

    Buy PP Needle punched Nonwoven Geotextile 30GSM-800GSM from China manufacturer

    Description of PP Needle Punched Nonwoven Geotextile

    PP Needle punched Nonwoven Geotextile is mainly made of PP or PET short fiber and is produced by non-woven process. It has functions of isolation, filtration, drainage, reinforcement, protection and maintenance, etc.

    80g/m2~1500g/m2; width 1-6meters, length according to customer needs.

    Can be manufactured up to a width of 6 meters, leading to less loss of material.

    Both white and tinted varieties of geotextile are manufactured from 100% pure yarn. No recycled material is used.

    Products can be manufactured with surface weight ranging from 50 gr/m2 to 1000 gr/m2.

    1)Material:PP/ PET (Polypropylene/Polyester)
    2) Weight: 100--800g/M2
    3) Thickness: 0.9mm TO 5.0mm
    4) Width: 50-660cm

Specification of PP Needle Punched Nonwoven Geotextile

Properties Test Method Unit 200g 500g
Tensile Strength ASTM D4595 KN/m 15 32
Elongation at maximum load ASTM D4595 % 50 50
Grab Strength ASTM D4632 N 710 1560
Grab Elongation ASTM D4632 % 50 50
Trapezoidal Tear ASTM D4533 N 275 616
Burst Strength-CBR Plunger Method ASTM D6241 N 2150 5300
Puncture Resistance ASTM D4833 N 454 1028
Drop Cone Resistance(hole-Ø) BS EN 918 mm 27 14

Features of PP Needle punched Nonwoven Geotextile

1) UV resistant

2) High temperature resistance to up to 230℃ maintaining structure stability and original physical properties.

3) High flat drainage and vertical permeability.

4) High creep resistance.

5) Resistance of erosion of chemicals in soil as well as the corrosion of gasoline and diesel etc.
