PP Woven Geotextile

    Description

    Geotextile is a high strength polypropylene woven fabric produced from high tenacity tapes.

    Description of PP Woven Geotextile

    1. High strength, with identical strength of warp and weft when necessary.

    2. The woven geotextile undergoes a stabilizing process in production so that it has fair stability and creep behavior.

    3. The geotextile has a breadth of 8m such that lapping is reduced and lapping strength in increased.

    4. The woven geotextile serves multiple purposes of separation, water discharge and seepage prevention.

    5. Competitive advantage. Light weight, High strength, Good integrity, Convenient application, Effectivereinforcement, Low cost.

Application of PP Woven Geotextile

Used in project of highway, railway, sports ground, dam, water and soil project, tunnel, Coastal farmland reclamation, mine, environmental protection and coastal tidal land for anti-leakage, filtering, draining, isolating. Also can be made of industry bag, etc.

Package of PP Woven Geotextile

Width 1m-6m, length 50m-700m (or at request).

Specification of PP Woven Geotextile

Item Unit 25-20KN 30-20KN 40-28KN 60-42KN 80-56KN 100-70KN
Unit Weight g/m2 136(200lbs) 150 200(315lbs) 320 430 550
Tensile Strength Longitudinal KN/m 26.5 31.70 40.50 62.60 82.2 103.9
Transverse KN/m 20.6 28.20 43.00 57.2 72.4
Elongation At break Longitudinal % 175 18.9 18.6 18.8 19 20.8
Transverse % 151 17.8 17.8 17.8 17.9 20.9
Grab Tensile Strength KN 0.89 1.2 1.40 2.20 2.50 3.90
CBR Puncture Resistance KN 2.5 2.8 3.60 7.40 8.50 10.20
