Biaxial Geogrid BX1200
Quantity
Inquiry

Biaxial Geogrid BX1200

    Description

    Plastic Biaxial PP Geogrid is an integrally formed structure, which especially designed for soil stabilization and reinforcement applications.

    Description of biaxial geogrid bx1200

    PP Biaxial Geogrid is an integrally formed structure, which especially designed for soil stabilization and reinforcement applications. EltGrid-PPBG biaxial geogrid is manufactured from Polypropylene, from the process of extruding, longitudinal stretching and transverse stretching.

Specification of biaxial geogrid bx1200

Specification BX1200
Index unit MD, CD
Ultimate Tensile strenth KN/m 19.2, 28.8
Aperture Size mm 25x33
Tensile strength @2% strain KN/m 6.0, 9.0
Tensile strength @5% strain KN/m 11.8, 19.6
junction efficiency % 93
flexural stiffness mg-cm 750,000
Resistance to installation damage %SC/%SW/%GP 95/93/90
Resistance to long term degradation % 100
Resistance to UV degradation % 100
unit weight g/m2 320-400
Rolls dimensions (length, width) m 50*3.95, 50*2, 50*3

Application of biaxial geogrid bx1200

● Retaining retaining walls / steep slopes.

● Landslide Repair.

● Structural layers supporting road, railway and airport construction.

● Soft soil stabilization.

● Earth embankments over piles.
